Formal Property Checking
Questa Property Checking (PropCheck) supports general assertion-based formal verification to ensure that the design meets its specific functional requirements.
-
Sessions
-
Formal for Over-Constraint and Reachability Analysis
In this session we’ll review what makes a design observable and controllable by doing reachability analysis. -
Formal Coverage
This session will demo formal coverage using Questa PropCheck. -
Inconclusive Debug
This session will demo how to debug an inconclusive property using Questa PropCheck. -
Introduction to Formal Assertion-Based Verification
In this session we will learn about various formal verification techniques; what they are, how to utilize them, and benefits received from advanced formal technologies. -
Basic Formal Closure (Black Boxing and Cutpoint)
At some point formal engines will begin to struggle under the weight of the state space. This session will show two simple techniques to safely limit the states the engines need to process, enabling more in-depth results. -
Formal Model Checking
In this session we'll share some basic tips for getting started with direct property checking, how to setup the analysis for rapidly reaching a solution, and how to answer the question, “Do I have enough assertions?" -
Questa PropCheck
This session will demo the Questa PropCheck tool and will review features including the details window, properties window, along with source, waveform and schematic debug features. -
ABV and Formal Property Checking
This session will discuss how to successfully plan and integrate formal verification into your ABV flow.
-
-
Overview
Questa Property Checking (PropCheck) supports general assertion-based formal verification to ensure that the design meets its specific functional requirements. With support for PSL, SVA, and OVL, including multi-clocked assertions, PropCheck easily verifies even very large designs with many assertions; analyzing the behavior of the design vs. the desired behavior described by the assertions to identify all design states that are reachable from the initial state.
This analysis allows PropCheck to explore the whole state space in a breadth-first manner, in contrast to the depth-first approach used in simulation. PropCheck is therefore able to exhaustively discover any design errors that can occur, without needing specific stimulus to detect the bug. This ensures that the verified design is bug-free in all legal input scenarios.
At the same time, this approach inherently identifies unreachable coverage points, which helps accelerate coverage closure. Under the hood, PropCheck’s world-class, high capacity, high throughput engines effectively build on their respective strengths by cooperating with each other in real time; thus completing verification faster.
Sharing a common language front end with the Questa Advanced Simulator and leveraging the integration with the Unified Coverage Database (UCDB), Questa PropCheck is the perfect tool to accelerate bug detection, error correction and coverage closure.
-
