by Christine Lovett, Bryan Ramirez & Stacey Secatch, Xilinx, Inc. Michael Horn, Mentor Graphics Corporation
Modern FPGA and ASIC verification environments use coverage metrics to help determine how thorough the verification effort has been. Practices for creating, collecting, merging and analyzing this coverage information are well documented for designs that operate in a single configuration only. However, complications arise when parameters are introduced into the design, especially when creating customizable IP.
This article will discuss the coverage-related pitfalls and solutions when dealing with parameterized designs.
INTRODUCTION
Code reuse is increasingly common, mostly because it helps to make engineers more productive. Through reuse it is possible to use a single code base tuned to specific requirements in lieu of maintaining multiple code bases. A standard ASIC technique is to use strap signals along with register programming at the start of operation to generate a customized configuration. Designs on programmable fabric can take this one step further. The downloadable netlist can be configured by the use of parameters, which
...
