How to create a SystemVerilog testbench for my ALU's parent circuit?

I made an alu.sv module (with simple SystemVerilog code blocks like 5'b00000: alu_out = a + b; // ADD) that is thoroughly tested with its own testbench that I already created. In total, the ALU has thirteen different functions (ADD, SUB, MUL, etc.).
I followed this video to make my ALU’s testbench (with an external file): https://youtu.be/Hu9V0_ffp30?si=hJz5uN5JNv9nHdnR

I also built a main.sv file to wrap the ALU module inside it with: one clock (all components on posedge), one program counter (range from 0 to 7), one 16-bit wide RAM (to store two 8-bit wide operands a and b that will go INTO the ALU) with 256 unique locations (range from 0 to 255), the ALU module (from alu.sv == accepts two 8-bit operands, performs one function according to a 5-bit opcode passed (here, a 5-bit opcode corresponds to a specific function (like 00000 == ADD)), gives an 8-bit output stored in alu_out), and one register that stores an 8-bit number on posedge. This completes the introduction.
What I actually need is a testbench that can test my main.sv thoroughly (challenging my circuit to find holes).
I am new to testbench creation and its related concepts. One thing I saw a while ago is the Universal Verification Methodology (UVM) to create testbenches according to the universal standard. Is there any use of the methodology in my circuit or my circuit is too simple to include that?

I am not going to watch a video, but UVM is a good general approach for a circuit like yours. It depends mostly on your desire to learn UVM.

1 Like

I did watch the video and it shows an example of creating directed tests via a text file.

This is fine for a very simple DUT but if the DUT is more complex, then it is limited to the stimulus scenarios that the testbench creator can think of.

UVM enables constrained random stimulus so that the testbench can generate stimulus scenarios that you may not have thought of. If taking the testvector approach, you would probably write vectors to test each individual operand of the (ADD, SUB, MUL, etc), But what about sequential combinations ? e.g. ADD followed by SUB or MUL followed by another MUL ? There might be a case where consecutive MUL operands take longer to calculate the result meanwhile the RAM receiving the operands to perform overflows.

There are a few Youtube videos showing an ALU being verified by UVM

e.g. https://www.youtube.com/watch?v=qDp6U_nBFao

If you are new to UVM, then you might want to use the UVM Framework from Siemens EDA that you can download here in Verification Academy.

1 Like
