Hi,
I am working on a assertion where signal “a” and “b” are completely independent signals and when posedge of signal “a” is there then wait for signal “b” to go low irrespective of clock and any other signal once it goes low wait for 5 cycles to check if it stays low for that cycles if not then try again when signal “b” goes low eventually when signal b stays low more then 5 cycles then after the posedge of signal “b” check that signal “c” stays low for 2 clock cycles. I am not sure that below code will work.
Your requirements are difficult to understand because it is too verbal and everything was put into one very long sentence. Perplexity.ai did a good job at rephrasing the requirements to:
Requirements Breakdown
Signal “a” and “b” are independent.
On the posedge of signal “a”, wait for signal “b” to go low.
Once signal “b” goes low, check if it stays low for 5 cycles.
If signal “b” does not stay low for 5 cycles, retry when signal “b” goes low again.
When signal “b” stays low for more than 5 cycles, after the posedge of signal “b”, check that signal “c” stays low for 2 clock cycles
Sorry to tell you this, but your new requirements are very peculiar in that you sometimes use the variable forthe event, then switch to a clocking to test its duration.
The foillowing is close to what you want, but is illegal:
p: assert property( @(posedge a) 1|-> // ILEGAL
first_match( (@(negedge b) ##0 @(posedge clk) !b[*5]) [*1:$]) ##0 @(posedge b) ##1 @(posedge clk) !c[*2]);
** Error: (vsim-3937) Asserting on an illegal multiply clocked temporal expression. The clock flow cannot change in the operand of ‘first_match’ operator.
I suggest that you use an automatic task called by @(posedge a) and then use fork-join_none statements to get what you need. Immediate assertions can then be used from within the task.
Hi Ben,
i have written a immediate assertion for this but i am not sure when signal “a[0]”,“a[1]” and “a[2]” are triggered same time as they are different signals how the count variables will be taken care in this can you suggest any improvements.
always @(posedge a[0] or posedge a[1] or posedge a[2]) begin
fork
begin
if(o)begin
count =0;
repeat(20)begin
@(negedge b);
count =0;
repeat(5) begin
@(negedge clk);
if(!b)begin
count++;
end
end
if(count == 5) begin
@(posedge b);
repeat(2) begin
@(negedge clk);
assert (!c)
$info("assertion_debug PASSED");
else
$error("assertion_debug FAILED");
end
break;
end
end
end
end
join_none
end
I don’t quite understand your question, but here is my take:
module mx;
bit a, b, c, clk;
/* Signal “a” and “b” are independent. means no clock requited async signals
On the posedge of signal “a” then wait for negedge of signal “b” .
Once signal “b” goes low, check if it stays low for 5 cycles if not then check for subsequent negedge for signal b for this requirement.
When signal “b” stays low for more than 5 cycles, after the at posedge of signal “b”, check that signal “c” stays low for 2 clock cycles
*/
// Task triggering
ap: assert property( @(posedge a) 1|-> (1, t_abcd()));
// first_match( (@(negedge b) ##0 @(posedge clk) !b[*5]) [*1:$]) ##0 @(posedge b) ##1 @(posedge clk) !c[*2]);
task automatic t_abcd(); //
int count;
bit is_matched, go;
@(negedge b)
fork
begin : p1 // (@(negedge b) ##0 @(posedge clk) !b[*5]) [*1:20]
// count =0;
repeat(20)begin
count =0;
repeat(5) @(negedge clk) if(!b) count++;
if(count == 5) go=1;
disable p1;
end
am_no5b0: assert(0) else $display("assertion_debug NO count==5");
disable p2;
end
begin : p2
wait(go); // ##0 @(posedge b) ##1 @(posedge clk) !c[*2]);
@(posedge b);
repeat(2) begin
@(negedge clk);
assert (!c)
$info("assertion_debug PASSED");
else
$error("assertion_debug FAILED");
end
end
join
endtask
endmodule
The following assertion might do the trick. I have no way to test it other than that it compiles w/o error.
ap: assert property(
@(posedge a) 1 ##0 @(negedge b) ##0
@(posedge clk) (!b[->1] ##0 !b[*1:5] ##1 b)[*0:$] ##0
!b[->1] ##0 !b[*6] |->
@(posedge b) 1 ##1 @(posedge clk) !c[*2]);
I think that triggering on negedge b and on posedge b is not necessary, posedge clk is fine.
Hi Ben,
code is same as you provided but my compiler is different. what can be the work around?
module mx;
bit a, b, c, clk;
/* Signal “a” and “b” are independent. means no clock requited async signals
On the posedge of signal “a” then wait for negedge of signal “b” .
Once signal “b” goes low, check if it stays low for 5 cycles if not then check for
subsequent negedge for signal b for this requirement.
When signal “b” stays low for more than 5 cycles, after the at posedge of signal “b”,
check that signal “c” stays low for 2 clock cycles
*/
// Task triggering
ap: assert property( @(posedge a) 1|-> (1, t_abcd()));
// first_match( (@(negedge b) ##0 @(posedge clk) !b[*5]) [*1:$]) ##0 @(posedge b)
##1 @(posedge clk) !c[*2]);
task automatic t_abcd(); //
int count;
bit is_matched, go;
@(negedge b)
fork
begin : p1 // (@(negedge b) ##0 @(posedge clk) !b[*5]) [*1:20]
// count =0;
repeat(20)begin
count =0;
repeat(5) @(negedge clk) if(!b) count++;
if(count == 5) go=1;
disable p1;
end
am_no5b0: assert(0) else $display("assertion_debug NO count==5");
disable p2;
end
begin : p2
wait(go); // ##0 @(posedge b) ##1 @(posedge clk) !c[*2]);
@(posedge b);
repeat(2) begin
@(negedge clk);
assert (!c)
$info("assertion_debug PASSED");
else
$error("assertion_debug FAILED");
end
end
join
endtask
endmodule
